Panoramica tecnica
Telaio
Telaio:
SCOR 4060 Z Full Carbon Frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm Rear Travel | Fully Guided Internal Cable Routing | Boost 148 | SRAM UDH
Forcella:
RockShox ZEB | 150mm Travel | 44mm Rake
Sospensioni
Sospensione Anteriore:
RockShox ZEB | 150mm Travel | 44mm Rake
Sospensione Posteriore:
RockShox Super Deluxe Select | Rebound adjust
E-System
Unità di Trasmissione:
SHIMANO Steps EP8 DU-EP800
Batteria:
Darfon 36V | SHIMANO Steps service included | 720 Wh
Linee guida sulla sicurezza delle batterie agli ioni di litio di NYC
Display:
SHIMANO Steps EP8 Wireless Cycle Computer SC-EM800
Controllo Dell'unità di Trasmissione:
SHIMANO Steps EP8 Left Switch Unit SW-EM800-L
Caricabatterie:
Darfon Smart Plus 100-240V | 4A | US
Cockpit
Attacco Manubrio:
SCOR Alloy Stem | 3D Forged | 31.6mm Bar Bore | 35mm Length | 0° Angle
Piega:
SCOR Alloy Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 9° Backsweep
Nastro:
VP VPG-125A
Seat
Reggisella:
X-Fusion Manic | S 125mm | M 150mm | L / XL 170mm Travel
Sella:
Fizik Terra Alpaca X5
Gruppo
Guarnitura:
SHIMANO FC-EM600 | 165mm Length
Corona:
34T
Pacco pignoni:
SHIMANO Deore CS-M6100-12
Ingranaggi:
10-51T
Catena:
SHIMANO CN-M6100
Cambio:
SHIMANO Deore SLX RD-M7100
Comandi:
SHIMANO Deore SLX SL-M7100-R
Rapporti:
1 x 12
Freni
Leve Freno / Pinze:
SHIMANO Deore | BL-M6100 Levers | BR-M6120 Calipers
Dischi freno:
SHIMANO SM-RT66
Diametro dischi:
203mm
Ruote
Cerchi:
XDH-130 | 32 Spokes | 6061-T6 Alloy | Welded Joint | 30mm Internal Width | Tubeless ready
Mozzi:
XDH-130 | 32 Spokes | Sealed Cartridge Bearings
Pneumatici:
Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra DD TR (R)
Informazioni Tubeless:
Tubeless Ready Rims | Tubetype Tires
Informazioni aggiuntive
Sezione max coperture:
Width: 64mm | Diameter: 750mm
Peso senza Pedali:
22.80kg
Classificazione ASTM:
Level 4
Limite di peso massimale :
130kg
Regolamento sulla sicurezza generale dei prodotti (GPSR):
Avvertenze di sicurezza GPSR (UE)
Persona responsabile ai sensi del GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | 155 - 170 | 165 - 180 | 175 - 190 | 185 - 200 |
| BB Drop (SLACK) | 29 | 29 | 29 | 29 |
| BB Drop (STEEP) | 27 | 27 | 27 | 27 |
| BB Height (SLACK) | 340 | 340 | 340 | 340 |
| BB Height (STEEP) | 342 | 342 | 342 | 342 |
| Chainstay | 436 | 436 | 436 | 436 |
| Fork Length | 560 | 560 | 560 | 560 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center (SLACK) | 765 | 790 | 815 | 845 |
| Front Center (STEEP) | 752 | 777 | 802 | 832 |
| Head Tube | 87 | 99 | 115 | 127 |
| HT Angle (SLACK) | 64.5 | 64.5 | 64.5 | 64.5 |
| HT Angle (STEEP) | 65.5 | 65.5 | 65.5 | 65.5 |
| Reach (SLACK) | 440 | 465 | 490 | 520 |
| Reach (STEEP) | 436 | 461 | 484 | 516 |
| Seat Tube | 400 | 425 | 440 | 470 |
| ST Angle @750mm Saddle Height (SLACK) | 77 | 77 | 77 | 77 |
| ST Angle @750mm Saddle Height (STEEP) | 76.5 | 76.5 | 76.5 | 76.5 |
| ST Angle Actual (SLACK) | 69.4 | 69.4 | 69.4 | 69.4 |
| ST Angle Actual (STEEP) | 69 | 69 | 69 | 69 |
| ST Angle Effective (SLACK) | 78.5 | 78.5 | 78.5 | 78.5 |
| ST Angle Effective (STEEP) | 78 | 78 | 78 | 78 |
| Stack (SLACK) | 597 | 608 | 622 | 633 |
| Stack (STEEP) | 599 | 611 | 625 | 636 |
| Stand Over Height (80 in Front of BB) | 752 | 764 | 768 | 784 |
| Stand Over Height (Lowest Point) | 714 | 723 | 731 | 741 |
| Top Tube (SLACK) | 560 | 589 | 620 | 654 |
| Top Tube (STEEP) | 561 | 590 | 621 | 655 |
| Wheelbase (SLACK) | 1198 | 1223 | 1248 | 1278 |
| Wheelbase (STEEP) | 1185 | 1210 | 1235 | 1265 |
